PROFIS DF Diaphragm

#2097338

PC software to design a cost-effective fastening solution for steel deck diaphragms

  • Graphic card requirement: DirectX9 compatible graphics adapter with 64 MB RAM
  • Minimum required disc space: 200 MB
  • Memory (RAM) requirements: 500 MB

Customers also searched for decking designdeck design softwaremetal deck design programmetal deck design software or deck fasteners software.

Choose options

Pack size
  • 1 pc
Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices. Prices vary for Hawaii, Alaska and US Territories.

$0.00

Technical Data

Graphic card requirement
DirectX9 compatible graphics adapter with 64 MB RAM
Minimum required disc space
200 MB
Memory (RAM) requirements
500 MB
Supported operating system
Windows 10, Windows 8, Windows 7

Documents

Features & Applications

Features

  • Makes steel roof/floor deck system design easy
  • Choice of puddle welds, screws or Hilti mechanical fasteners
  • Design optimization feature to produce the most cost-effective design solution
  • Fastener estimation tool for improved cost estimation
  • Available to download free of charge from your local Hilti website

Applications

  • Steel deck, roof and floor systems designed in accordance with the SDI Diaphragm Design Method
  • Includes the latest ICC-ES AC43 performance data
  • Specification of steel deck attachment solutions or creation of submittals for existing projects
