TE-CD (SDS Plus) Metric hollow drill bit
Ultimate SDS Plus (TE-C) hollow drill bit for virtually dust-free hammer drilling in concrete
- Connection end: TE-C (SDS Plus)
- Base material: Reinforced concrete, Concrete
- Working mode: Hammer drilling
ultimate
Customers also searched for dust-free drill bit, dust extraction drill bit , hollow drill bit or SDS plus.
Choose options
Diameter
- 12 mm
- 14 mm
Working length
- 200 mm
- 240 mm
Length
- 330 mm
- 370 mm
Pack size
- 1 pc
Quantity
Packs
Total Pieces
1
Discounted net
From $100.00
Technical Data
Connection end
TE-C (SDS Plus)
Base material
Reinforced concrete, Concrete
Working mode
Hammer drilling
Head shape
Multi Cutter
Head material composition
Tungsten carbide
Need vacuum cleaner
Yes
Product Class
Ultimate
Documents
pdf OSHA 1926.1153, Section VII (2), English [ 605.6 KB ]
Features & Applications
Features
- Drilling and hole cleaning in one step
- Optimum hole cleaning for consistent anchor setting
- Robustness, lifetime and drilling speed equal to TE-YX drill bits
- Minimized snagging or sticking when drilling into rebar
Applications
- Drilling holes for anchoring structural steel connections (e.g. steel columns, beams)
- Drilling holes for structural connections with post-installed rebar
- Drilling holes for anchoring secondary steel structures (e.g. staircases, steel ledgers)
- Drilling holes for structural renovation or upgrading with post-installed rebar
- Drilling holes for substitution of misplaced or missing rebars
For approval or certificate information, please see individual items.
