TE-YX (SDS Max) Metric hammer drill bit

Hammer drill bit TE-YX 12/32 #2179043

Ultimate SDS Max (TE-Y) hammer drill bit for exceptional drilling performance in reinforced concrete (metric)

  • Connection end: TE-Y (SDS Max)
  • Base material: Reinforced concrete, Concrete, Masonry, Brick, Limestone
  • Working mode: Hammer drilling

Customers also searched for SDS maxhammer drill bitconcrete drill bit or masonry drill bit.

Choose options

Diameter
  • 12 mm
  • 15 mm
  • 16 mm
  • 18 mm
  • 22 mm
  • 24 mm
  • 25 mm
  • 28 mm
  • 32 mm
  • 37 mm
  • 40 mm
  • 45 mm
  • 55 mm
Working length
  • 200 mm
  • 250 mm
  • 400 mm
  • 450 mm
  • 800 mm
  • 1170 mm
Length
  • 320 mm
  • 370 mm
  • 520 mm
  • 570 mm
  • 920 mm
  • 1300 mm
Pack size
  • 1 pc
Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices. Prices vary for Hawaii, Alaska and US Territories.

Discounted net

$139.00

$139.00 / 1 Each

Technical Data

Connection end
TE-Y (SDS Max)
Base material
Reinforced concrete, Concrete, Masonry, Brick, Limestone
Working mode
Hammer drilling
Head shape
Multi Cutter
Head material composition
Tungsten carbide
Diameter
12 mm
Length
320 mm
Working length
200 mm

Features & Applications

Features

  • Optimized multi-cutter (4 or 6-cutter) carbide head – superior drilling performance and less jamming when hitting rebar
  • Heat-treated flute offers superior wear resistance and maximum robustness, with a wear mark to estimate the bit's suitability for setting anchors
  • Slimmer and lighter helix for more comfortable drilling and superior drilling speed
  • Fully embedded drill bit head for maximum robustness and longer life
  • In the unlikely event of breakage, the drill bit will be considered for replacement as long as the wear mark on the helix is still visible

Applications

  • Hammer drilling in reinforced concrete, concrete, masonry and other construction materials
  • Drilling holes for all chemical anchor installation purposes
  • Drilling anchor holes for all mechanical anchor installation purposes
  • Installing rebar using Hilti injectable adhesive mortar
  • Extra-long drill bits available for renovation work, e.g. sealing joints in masonry and concrete to prevent water penetration
