MH-SLT Speed lock trapeze hanger

Split nut w/slotted washer 1/2" #2008781

Configurator
Technical Data
Documents
Features & Applications
Related Products
IS_HNA_0021_o.eps

Slotted washer and split nut for quick installation of trapeze hangers

  • Wrench size: 7/8 in
  • Material composition: Carbon steel
  • Surface finish: Indoor Coated - Electro galvanized

Choose options

Thread connection - M
  • 1/2 in
Wrench size
  • 7/8 in
Pack size
  • 40 pc
 Product options
Quantity
Box
Total Pieces
40
You cannot see your company prices

Please Log in or register to see your company prices. Prices vary for Hawaii, Alaska and US Territories.

Discounted net
$223.00
$223.00 / 1 Box

Technical Data

Wrench size
7/8 in
Material composition
Carbon steel
Surface finish
Indoor Coated - Electro galvanized
Maximum load - F
1350 lbf
Environmental conditions
Dry indoor conditions (C1) Indoor with temporary condensation (C2)
Weight
1.56 lb

Documents

Documentation
Technical information
Operating Instruction
pdf Corrosion handbook, English [ 9.6 MB ]

Features & Applications

Features

  • Nut and washer can be installed at any position on the threaded rod, for quick and accurate trapeze building
  • Significant time saving over traditional nut solution

Applications

  • Use split nut only in conjunction with slotted washer and 1 5/8” wide strut
