DD 30-W Core drill
Compact, light diamond coring machine for wet, handheld coring of heavy-duty anchor and rebar holes from 8-35 mm (5/16 - 1-3/8") in diameter
- Diameter range: 5/16 - 1-3/8 in
- Base material: Concrete, Masonry
- Operation mode: Hand-held and rig-mounted drilling system
Technical Data
Diameter range
5/16 - 1-3/8 in
Base material
Concrete, Masonry
Operation mode
Hand-held and rig-mounted drilling system
Number of gears
1
No load RPM
gear 1: 9200 rpm
Weight according EPTA-Procedure 01/2003 without battery
16.8 lb
Dimensions (LxWxH)
16.9 x 5 x 9.4 in
A-weighted emission sound pressure level
88 dB (A) 1
Tri. vibr. value for drilling into concrete (wet) with diamond core A (ah,DD)
6 m/s²
Tri. vibr. value for drilling into concrete (wet) (ah,DD) - Corebit A
C+ 18/300 SPX-T
Corner accessibility
1.8 in
- According to the applicable product standard (see the Operating Instruction for more details)
Documents
Features & Applications
Features
- Very low drilling noise – the ideal solution for drilling in inhabited buildings
- Impact-free drilling reduces the risk of damage to brittle materials and allows drilling close to edges
- Fast drilling through rebar thanks to the unique TopSpin technology
- Soft-start feature for precise hole positioning
- The quick-lock keyless chuck system makes changing core bits quicker and easier than ever
Applications
- Drilling accurate anchor holes and through holes 8 to 35 mm (5/16 - 1-3/8") in diameter
- Low-noise drilling for setting anchors during renovation work in hospitals, commercial and residential buildings
- Wet coring in heavily-reinforced concrete, masonry and natural stone
- Wet coring in brittle materials (marble, tiles, masonry, natural stone) and close to edges
For approval or certificate information, please see individual items.
