PROFIS Anchor Channel design software
New productItem #r3604720
Structural engineering software for efficiently calculating and modeling cast-in anchor channels according to building codes and regulations
- Additional Accessory Information: Attention HAC XT Customers: The interaction equation per AC232 included in PROFIS Anchor Channel version 1.7.1 may be unconservative when designing per ACI 318-11. Please contact the HILTI HAC Team at US+CA.HAC@Hilti.com for additional information and guidance when designing with this condition.
- Security and authorizations: Hilti signed software
- Supported operating system: Windows 10, Windows 8, Windows 7
Highlights
PROFIS Anchor Channel calculating and modeling software is designed to help you produce more accurate fastening points in concrete using anchor channels in less time. The fastening calculations are supported by the most up-to-date modeling codes and regulations.
Complete your calculations and choose a fastening solution from recommendations based on the calculated scenarios. The software can then generate a design report, including formulas, code and approval references and anchor channel specifications.
Fastening calculations for almost every scenario, including seismic and dynamic loading, are based on customized, pre-approved parameters in accordance with regional building regulations. You can calculate anchor channel systems for various design regulations and loads using calculations according to ICC-ES AC232, ACI 318-08, 318-10, 318-11, and ACI 349.
The Hilti Design Method helps solve for anchor channel detailing not included in standard design guidelines, enabling you to find more efficient solutions for complex anchor combinations.
This software makes it easier to make the switch from designing with traditional alternatives. Compared to traditional cast-in technologies, anchor channels help you save on skilled labor as they require no welding. Additionally, anchor channels can reduce the installation time per connection, improve jobsite safety and increase structural reliability.
Your local Hilti anchor channel team is on hand to provide additional information and guidance when designing.
Technical Data
PROFIS Anchor Channel
Design anchor channel systems easier and accurately
PROFIS Anchor Channel calculating and modeling software is designed to help you produce more accurate anchor channel system designs in less time.
Our fastening calculations are supported by the most up-to-date modeling codes and regulations so you can be confident in your designs. Additionally, Hilti's state-of-the-art design method helps solve for scenarios not included in standard design guidelines, enabling you to find more efficient solutions for complex anchor combinations.
Reduce Design Time
Design for multiple anchor channel system applications in a 3D environment for easy visualization and faster designing.
Increase Productivity
Complete calculations, choose a fastening solution, and generate a comprehensive report from one application.
Improve Accuracy
Fastening calculations for almost every scenario, including seismic and dynamic loading, are based on customized, pre-approved parameters.
Features
Comprehensive Calculations
Calculate anchor channel systems for multiple design regulations and loads using calculations per ICC-ES AC232, ACI 318-08, 318-10, 318-11, and ACI 349.
Product Recommendation
Select anchor channel fasteners from a product recommendations list based on calculated scenarios.
Design Reporting
Generate a design report, including formulas, code and approval references and anchor channel specifications.
Approval Library
Access product approvals from our robust library for a comprehensive report.
Seismic Calculations
Design anchor channel fastenings for seismic applications in accordance with regional building regulations.
