Compact triple-mode SDS Plus (TE-C) rotary hammer – for hammer drilling, precision hammer drilling and rotary-only drilling

  • Weight according EPTA-Procedure 01/2003 without battery: 6 lb
  • Optimum Hammer drilling range: 5/32 - 15/32 in
  • Single impact energy: 1.3 ft-lbs

Customers also searched for SDS plus rotary hammerconcrete hammer drillhilti hammer drillhammer drill or SDS plus hammer drill.

Technical Data

Weight according EPTA-Procedure 01/2003 without battery
6 lb
Optimum Hammer drilling range
5/32 - 15/32 in
Single impact energy
1.3 ft-lbs
Working mode
Hammer drilling, Drilling, Fine hammer drilling
Hammer drilling diameter range
5/32 - 7/8 in
Hammer drilling RPM
1200 rpm
Full hammering frequency
4600 impacts/minute
Functionality
Power reduction, Reverse mode, Depth gauge
Triaxial vibration value for hammer drilling into concrete (ah,HD)
12.1 m/s² 1
Triaxial vibration for chiseling into concrete
13.5 m/s² 2
A-weighted emission sound pressure level
91 dB (A) 3
Dimensions (LxWxH)
13.9 x 3.5 x 8 mm
  1. According to the applicable product standard (see the Operating Instruction for more details)
  2. According to the applicable product standard (see the Operating Instruction for more details)
  3. According to the applicable product standard (see the Operating Instruction for more details)

Documents

Features & Applications

Features

  • Three-mode SDS Plus (TE-C) rotary hammer – for hammer drilling, rotary-only drilling and precision hammer drilling
  • Sturdy motor with high load rating for maximum reliability
  • Quick-change TE-C Click chuck and user-friendly selector switch for high working convenience
  • Electronic switch for precise drilling
  • 360° side handle adjusts easily for preference or use in tight spaces

Applications

  • Daily hammer drilling in concrete, masonry and natural stone
  • Precision hammer drilling feature for drilling into concrete and masonry, as well as brittle materials like tile and stone
  • Ocassional drilling in steel, wood and plastics using optional chuck adaptor
  • Driving screws using optional bit holder
  • Reverse feature assists in the removal of stuck drill bits
